LQ070Y3LG05 Technical Data

Enabling Customer Innovation to Empower Tomorrow's Technology
LQ070Y3LG05 supports display 800(RGB)×480 (WVGA) with aspect ratio of 16:9 (W:H), whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 153.6(W)×86.64(H) mm, outline size of 165(W)×104(H)×7.71(D) mm, viewing area size of 156.0(W)×89.04(H) mm, with surface treament of Antiglare, Hard coating (3H), net weight of 195g (Max.). As a TN, Normally White, Transmissive LCM product, LQ070Y3LG05 can provides 380 cd/m² display brightness 500:1 transimissive contrast ratio, 70/70/50/70 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on 6 o'clock , and response time of 16 (Typ.)(Tr+Td) ms.
Technical Data:
Part #：
LQ070Y3LG05
Brand：
SHARP
Size：
7 inch"
Resolution：
800×480
Interface：
7 inch
Technology：
Transmissive
Brightness：
380 (Typ.)
Operating Tem：
-10 ~ 70 °C
Storage Tem：
-30 ~ 80 °C
Contact Us
Name
Email
Telephone
Touch screen customize:
Cover Glass customize:
Demo Kits:
Message
Integrated Display solutions
Touch screen, standard ready-made and customization
Supportrting capacitive touch screen (I2C interface, SPI interface, USB interface, UART interface)/ resistive touch screen / touch structure and function customization / optical bonding manufacturing.
Specific features:
High cost effective, automotive grade, industrial grade, medical grade solutions.
Durable and sturdy design for extreme environments.
Supports glove touch, multi touch, and stylus touch.
Featuring waterproofing, salt water resistance, low reflectivity, and 3D gesture touch control .
Driver board/adapter board, standard ready-made and design customization
DEMO board, HDMI board, other customized board, etc
Embbed Integrated Solution
UART display solution, HMI display solution, WINDOW display solution, Android display solution, Raspberry Pi solution, portable secondary screen solution, etc.
