Ultra High Brightness Displays


Enabling Customer Innovation to Empower Tomorrow's Technology
Size
Resolution
Interface
Brightness
Operating Temp.
Outline Dim.
Model
Datasheet/Quote
0.95" High Brightness Display
128×128
SPI
1000
-20~70°C
25.24×27.14mm
ET095QF01-H
Get A Quote
0.95" High Brightness Display
120×240
SPI
1000
-20~70°C
12.8×27.35mm
ET095AM01-HT
Get A Quote
1.32" High Brightness Display
466×466
MIPI
700
-20~70°C
36.35×36.35mm
ET013XR01-HT
Get A Quote
1.4" High Brightness Display
128×128
CPU/SPI
800
-20~70°C
32.36×38mm
ET014QQ01-K
Get A Quote
1.45" High Brightness Display
172×320
Serial RGB
750
-20~70°C
19.39×36.28mm
ET015QV01-TS
Get A Quote
1.5" High Brightness Display
466×466
SPI
1000
-20~60°C
51.6×51.6mm
ET015SK01-VT
Get A Quote
1.54" High Brightness Display
320×320
MIPI
700
-20~70°C
31.52×33.72mm
ET015HV01-T
Get A Quote
1.54" High Brightness Display
320×320
TTL
700
-20~70°C
31.52×33.72mm
ET015HV06-T
Get A Quote
1.54" High Brightness Display
240×240
CPU
1000
-20~70°C
31.92×35.11mm
ET015QV02-T
Get A Quote
1.6" High Brightness Display
228×460
MIPI/CPU/SPI
700
-20~70°C
19.48×38.48mm
ET016AM01-HT
Get A Quote
1.75" High Brightness Display
466×466
MIPI
700
-20~70°C
47.4×47.4mm
ET018AM01-HT
Get A Quote
1.77" High Brightness Display
128×160
CPU
1000
-20~70°C
31.4×42.9mm
ET018QE01-PV
Get A Quote
1.77" High Brightness Display
128×160
Parallel Data
1000
-20~70°C
34.7×46.7mm
ET018QE02-SD
Get A Quote
1.9" High Brightness Display
1600×1200
MIPI
1000
-10~55°C
41.2×40.6mm
ET019HD01-AM
Get A Quote
1.9" High Brightness Display
410×502
MIPI/CPU/SPI
800
-20~70°C
38.27×45.25mm
ET019AM01-TT
Get A Quote
2.0" High Brightness Display
480×360
MIPI
900
-30~85°C
46.5×41.56mm
ET020WQ30-K
Get A Quote
2.0" High Brightness Display
368×448
MIPI
800
-20~70°C
34.64×42.89mm
ET020AM02-HT
Get A Quote
2.0" High Brightness Display
480×360
TTL
800
-30~85°C
46.5×41.56mm
ET020WQ20-KRT
Get A Quote
2.0" High Brightness Display
240×320
CPU/RGB/SPI
900
-20~70°C
36.72×56.74mm
ET020VG02-R
Get A Quote
2.0" High Brightness Display
480×640
TTL
700
-20~70°C
34.6×47.8mm
ET020VG01-R
Get A Quote
2.0" High Brightness Display
480×360
TTL
900
-30~85°C
46.5×41.56mm
ET020WQ20-K
Get A Quote
2.0" High Brightness Display
480×360
MIPI
820
-30~85°C
54.5×47.56mm
ET020WQ30-KT
Get A Quote
2.0" High Brightness Display
480×360
TTL
820
-30~85°C
54.5×47.56mm
ET020WQ20-KT
Get A Quote
2.1" High Brightness Display
480×480
TTL
1000
-20~70°C
56.18×59.71mm
ET021WV01-TS
Get A Quote
2.1" High Brightness Display
480×480
MIPI
1000
-20~70°C
56.18×59.71mm
ET021WV01-Z
Get A Quote
2.2" High Brightness Display
240×320
CPU/RGB/SPI
850
-20~70°C
41.7×56.16mm
ET022QV01-K
Get A Quote
2.2" High Brightness Display
640×320
MIPI
900
-20~70°C
51.94×31.39mm
ET022QV01-H
Get A Quote
2.3" High Brightness Display
320×480
TTL
700
-20~70°C
37.52×59.78mm
ET023QV01-R
Get A Quote
2.4" High Brightness Display
240×320
CPU/RGB/SPI
1500
-20~70°C
42.92×60.26mm
ET024VG10-T
Get A Quote
2.4" High Brightness Display
320×480
MIPI
750
-20~70°C
39.52×60.68mm
ET024HV30-K
Get A Quote
2.4" High Brightness Display
320×480
MIPI
700
-20~70°C
44.52×69.88mm
ET024HV30-KT
Get A Quote
2.4" High Brightness Display
320×480
TTL
750
-20~70°C
39.52×60.68mm
ET024HV20-K
Get A Quote
2.4" High Brightness Display
320×480
TTL
700
-20~70°C
44.52×69.88mm
ET024HV20-KT
Get A Quote
2.4" High Brightness Display
480×640
MIPI
800
-30~80°C
42.92×60.26mm
ET024VG30-K
Get A Quote
2.8" High Brightness Display
240×320
TTL
1000
-20~70°C
50.5×69.7mm
ET028VG02-C
Get A Quote
2.8" High Brightness Display
240×320
CPU/RGB/SPI
850
-20~70°C
50.2×69.2mm
ET028VG01-C
Get A Quote
2.8" High Brightness Display
240×320
MIPI
700
-20~70°C
50.5×69.7mm
ET028VG20-K
Get A Quote
2.8" High Brightness Display
240×320
MIPI
700
-20~70°C
50.5×69.7mm
ET028VG20-K
Get A Quote
3.2" High Brightness Display
262×928
MIPI
700
-20~70°C
23.8×81.05mm
ET032AM01-TOT
Get A Quote
3.4" Sunlight Readable Display
480×480
MIPI
1000
-20~70°C
65.72×69.64mm
ET034WV20-K
Get A Quote
3.4" High Brightness Display
480×480
MIPI
1000
-20~70°C
65.72×69.64mm
ET034WV20-K
Get A Quote
3.4" High Brightness Display
480×480
MIPI
850
-20~70°C
69.64×65.72mm
ET034WV02-KT
Get A Quote
3.4" High Brightness Display
800×800
MIPI
1500
-20~70°C
96.6×99.79mm
ET034FD01-HG
Get A Quote
3.5" High Brightness Display
640×480
MIPI
750
-20~70°C
94.08×74.8mm
ET035VG01-H
Get A Quote
3.5" Sunlight Readable Display
800×640
TTL
1000
-30~85°C
97.6×83.79mm
ET035CIR01
Get A Quote
3.5" High Brightness Display
800×480
TTL
850
-20~70°C
102.84×64.5mm
ET035VG01-F
Get A Quote
3.5" High Brightness Display
800×640
TTL
1000
-30~85°C
97.6×83.79mm
ET035CIR01
Get A Quote
3.5" High Brightness Display
800×640
TTL
1500
-20~70°C
97.6×83.79mm
ET035CR10-TRT
Get A Quote
3.5" High Brightness Display
640×480
TTL
750
-20~70°C
74.38×62.35mm
ET035VG20-K
Get A Quote
3.5" High Brightness Display
320×480
CPU/RGB/SPI
700
-30~85°C
55.5×84.86mm
ET035HV30-KRT
Get A Quote
3.5" High Brightness Display
320×480
CPU/RGB/SPI
720
-30~85°C
55.5×84.86mm
ET035HV30-KT
Get A Quote
3.5" High Brightness Display
240×320
CPU
900
-30~80°C
64.16×83.39mm
ET035VG01-TS
Get A Quote
3.5" High Brightness Display
320×240
CPU/SPI
1000
-20~70°C
76.5×63.7mm
ET035HV01-F
Get A Quote
3.5" High Brightness Display
800×640
TTL
1000
-20~70°C
97.6×83.79mm
ET035CR01-TST
Get A Quote
3.5" High Brightness Display
320×240
TTL
960
-20~70°C
84.4×71.5mm
ET035HV01-HT
Get A Quote
3.5" High Brightness Display
320×240
TTL
1400
-20~70°C
76.84×63.84mm
ET035HV03-T
Get A Quote
3.5" High Brightness Display
544×506
TTL
1000
-20~70°C
98.88×94.12mm
ET035CR01-T
Get A Quote
3.5" High Brightness Display
480×640
CPU/RGB/SPI
800
-20~70°C
64×85mm
ET035QV01-C
Get A Quote
3.5" High Brightness Display
320×480
CPU/RGB/SPI
800
-30~85°C
55.5×84.96mm
ET035HV20-K
Get A Quote
3.6" High Brightness Display
544×506
TTL
1000
-30~85°C
98.88×94.12mm
ET036CR01-T
Get A Quote
3.9" High Brightness Display
480×128
TTL
800
-30~85°C
103.2×34.85mm
ET039WQ01-H
Get A Quote
3.9" High Brightness Display
800×216
TTL
1000
-20~70°C
100.4×32.9mm
ET039WV01-HG
Get A Quote
3.9" High Brightness Display
480×128
TTL
850
-20~70°C
105.5×40.64mm
ET039WQ01-XFT
Get A Quote
4" High Brightness Display
720×720
MIPI
700
-30~80°C
77×80mm
ET040HD20-K
Get A Quote
4" High Brightness Display
720×720
LVDS
700
-30~80°C
77×80mm
ET040HD22-K
Get A Quote
4" High Brightness Display
720×720
TTL
700
-30~80°C
80×77mm
ET040HD21-K
Get A Quote
4" High Brightness Display
400×960
TTL
800
-20~60°C
42.9×95.7mm
ET040FW01-T
Get A Quote
4" High Brightness Display
480×800
MIPI
1000
-10~60°C
57.14×97.3mm
ET040WV01-EX
Get A Quote
4" High Brightness Display
720×720
MIPI
1200
-20~70°C
110×117.14mm
ET040HD30-T
Get A Quote
4.2" High Brightness Display
720×720
TTL
850
-30~85°C
132.5×132.5mm
ET042HD02-TST
Get A Quote
4.3" High Brightness Display
480×272
TTL
1100
-20~70°C
105.5×67.2mm
ET043WV01-ATT
Get A Quote
4.3" High Brightness Display
1920×1080
LVDS
1000
-20~70°C
106.34×66.01mm
ET043FH01-Z
Get A Quote
4.3" High Brightness Display
800×92
TTL
800
-20~70°C
120.7×30mm
ET043BA01-ST
Get A Quote
4.3" High Brightness Display
480×272
HDMI
1000
-20~70°C
105.5×67.2mm
ET043WV01-TS-HDMI
Get A Quote
4.3" High Brightness Display
800×480
TTL
1050
-30~85°C
105.4×67.15mm
ET043WV21-KT
Get A Quote
4.3" High Brightness Display
800×480
TTL
1050
-30~85°C
105.4×67.15mm
ET043WV21-KRT
Get A Quote
4.3" High Brightness Display
480×800
TTL
800
-30~85°C
62×104.25mm
ET043WV09-TT
Get A Quote
4.3" High Brightness Display
480×272
TTL
1300
-20~70°C
105.45×67.2mm
ET043WV01-R
Get A Quote
4.3" High Brightness Display
800×480
TTL
1200
-20~70°C
105.5×67.2mm
ET043WV12-T
Get A Quote
4.5" High Brightness Display
1920×1080
LVDS
1200
-20~70°C
103.5×65.3mm
ET045FH10-T
Get A Quote
4.6" Sunlight Readable Display
800×320
TTL
850
-20~70°C
120.7×56.16mm
ET046BA01-S
Get A Quote
4.6" High Brightness Display
800×320
TTL
850
-20~70°C
120.7×56.16mm
ET046BA01-S
Get A Quote
4.6" High Brightness Display
800×320
TTL
700
-20~70°C
120.7×56.16mm
ET046BA01-ST
Get A Quote
5" High Brightness Display
600×600
MIPI
1000
-20~70°C
95.08×99.5mm
ET050SQ01-KD
Get A Quote
5" High Brightness Display
720×1280
MIPI
950
-20~70°C
70.01×116.29mm
ET050HD01-A
Get A Quote
5" High Brightness Display
600×600
MIPI
1000
-20~70°C
95.08×99.5mm
ET050SQ01-C
Get A Quote
5" High Brightness Display
1024×600
TTL
800
-20~70°C
120.7×75.8mm
ET050WS01-AM
Get A Quote
5" High Brightness Display
800×480
HDMI
800
-20~70°C
147×104mm
ET050WV01-KD-HDMI
Get A Quote
5" High Brightness Display
800×480
CPU
800
-20~70°C
120.7×93.83mm
ET050WV01-TS
Get A Quote
5" High Brightness Display
1080×1920
MIPI
1200
-20~70°C
64.76×118.7mm
ET050FH10-T
Get A Quote
5" High Brightness Display
800×480
TTL
1500
-30~85°C
120.7×75.8mm
ET050WV06-T
Get A Quote
5" High Brightness Display
1080×1920
MIPI
3000
-20~70°C
75.88×119.47mm
ET050FH01-H
Get A Quote
5" High Brightness Display
640×480
TTL
1000
-20~70°C
113.7×88.5mm
ET050VG01-ZK
Get A Quote
5" High Brightness Display
480×854
TTL
1000
-20~70°C
66.4×120.05mm
ET050FW0-H
Get A Quote
5.1" High Brightness Display
480×480
TTL
1000
-20~70°C
106×106mm
ET051SQ01-DB
Get A Quote
5.2" High Brightness Display
1080×1920
MIPI
1200
-20~60°C
77.5×137mm
ET052FH01-TT
Get A Quote
5.5" High Brightness Display
720×1280
MIPI
800
-20~70°C
70.34×128.1mm
ET055HD11-T-HDMI
Get A Quote
5.5" High Brightness Display
1080×1920
MIPI
2000
-20~70°C
83.7×141.2mm
ET055WU06-TT
Get A Quote
5.5" High Brightness Display
1080×1920
MIPI
1200
-20~60°C
75.8×139.9mm
ET055WU01-TT
Get A Quote
5.5" High Brightness Display
1200×1920
MIPI
2000
-20~70°C
/
ET055WU01-R
Get A Quote
5.5" High Brightness Display
720×1280
MIPI
1000
-20~70°C
70.34×128.1mm
ET055HD11-T
Get A Quote
5.5" High Brightness Display
1080×1920
MIPI
1200
-20~60°C
75.92×136.3mm
ET055FH10-TT
Get A Quote
5.6" High Brightness Display
640×480
TTL
1400
-20~70°C
126.5×100.2mm
ET056VG01-ST
Get A Quote
5.7" High Brightness Display
640×480
MIPI
1500
127.03×98.5
127.03×98.5mm
ET057VG01-ZT
Get A Quote
5.8" High Brightness Display
1280×768
Mini LVDS
1000
-20~70°C
137.488×84.7mm
ET058HD01-RX
Get A Quote
5.8" High Brightness Display
852×600
MIPI/RGB
880
-30~80°C
133.66×86.83mm
ET058WV01-R
Get A Quote
6" High Brightness Display
1080×1920
MIPI
800
-20~60°C
77.46×141.05mm
ET060FH01-AM
Get A Quote
6" High Brightness Display
720×1280
MIPI
1000
-20~70°C
87.52×149.14mm
ET060HD10-TT
Get A Quote
6.2" High Brightness Display
1024×600
Serial RGB
1500
-30~80°C
144.33×88.16mm
ET062WS02-F
Get A Quote
6.2" High Brightness Display
1024×600
MIPI
1500
-30~80°C
144.33×88.16mm
ET062WS01-F
Get A Quote
6.5" High Brightness
800×480
TTL
700
-30~85°C
155.2×89.4mm
ET065WV01-ZK
Get A Quote
6.5" High Brightness Display
1024×400
LVDS
800
-20~70°C
165×72.86mm
ET065BA01-S
Get A Quote
6.6" High Brightness Display
1080×2400
MIPI
770
-20~70°C
71.452×157.41mm
ET066AM01-A
Get A Quote
6.7" High Brightness Display
1920X1080
MIPI
2000
-30~85℃
/
ET067FH01-R
Get A Quote
6.7" High Brightness Display
1024×600
LVDS
1000
-30~80°C
160.2×90.3mm
ET067WS01-GL
Get A Quote
6.8" High Brightness Display
480×1280
MIPI
1000
-20~70°C
74.42×173.79mm
ET068BA07-T
Get A Quote
6.9" MIP Display
280×1424
MIPI
850
-20~70°C
43.3×201mm
ET069BA01-ZT
Get A Quote
7" High Brightness Display
1080×1080
LVDS
800
-20~70°C
191.58×192.75mm
ET070SQ01-T
Get A Quote
7" High Brightness Display
1024×600
TTL
1000
-30~80°C
164.9×100mm
ET070WS10-TC
Get A Quote
7" High Brightness Display
1024×600
LVDS
1600
-30~85°C
182×117.6mm
ET070WS07-KT
Get A Quote
7" High Brightness Display
1024×600
HDMI
1000
-20~70°C
175.8×109.24mm
ET070HD02-KDT
Get A Quote
7" High Brightness Display
1080×1920
MIPI
1000
-30~80°C
101.4×174mm
ET7D0023
Get A Quote
7" High Brightness Display
1080×1920
MIPI
2000
-20~70°C
102.5×175mm
ET070FH01-RT
Get A Quote
7" High Brightness Display
1024×600
MIPI
1500
-20~70°C
165x100mm
ET070HD01-KDRT
Get A Quote
7" High Brightness Display
1280×768
LVDS
1000
-30~85°C
164.06×104.66mm
ET070HD01-TST
Get A Quote
7" High Brightness Display
1200×1920
MIPI
1300
-20~70°C
105.18×163.34mm
ET070WU01-TT
Get A Quote
7" High Brightness Display
1920×1080
MIPI
3000
-20~70°C
164.19×97.87mm
ET070FH01-HT
Get A Quote
7" High Brightness Display
1024×600
MIPI
810
-20~70°C
182.07×117.6mm
ET070HD05-KT
Get A Quote
7" High Brightness Display
1024×600
MIPI
1700
-20~70°C
165×100mm
ET070HD05-K
Get A Quote
7" High Brightness Display
800×1280
MIPI
1100
-20~70°C
108.1×164.2mm
ET070WX10-TT
Get A Quote
7" High Brightness Display
1200×1920
MIPI
1500
-10~60°C
113.89×176.6mm
ET070WU18-OT
Get A Quote
7" High Brightness Display
1200×1920
MIPI
1500
-10~60°C
107.98×163.8mm
ET070WU12-O
Get A Quote
7" High Brightness Display
1200×1920
MIPI
1500
-10~60°C
160.8×98.7mm
ET070WU07-O
Get A Quote
7" High Brightness Display
1200×1920
MIPI
1500
-20~70°C
114.04×178.25mm
ET070WU15-TT
Get A Quote
7" High Brightness Display
800×480
LVDS
1100
-30~85°C
165.4×104.59mm
ET070WV21-K
Get A Quote
7" High Brightness Display
800×480
TTL
1140
-30~80°C
190.5×105.4mm
ET070WV07-KT
Get A Quote
7" High Brightness Display
800×480
TTL
700
-20~70°C
164.9×100mm
ET070WV01-T
Get A Quote
7" High Brightness Display
1280×800
LVDS
1300
-20~70°C
162.3×107.9mm
ET070WX01-STT
Get A Quote
7.1" High Brightness Display
1080×1920
MIPI
700
-20~70°C
89.13×160.91mm
ET071AM01-HT
Get A Quote
7.2" High Brightness Display
1280×370
TTL
1000
-20~70°C
186.18×67.35mm
ET072BA01-S
Get A Quote
7.5" High Brightness Display
800×800
MIPI
1000
-20~70°C
142.56×148.24mm
ET076MBA1-GXT
Get A Quote
7.5" High Brightness Display
800×480
SPI
1500
0~50°C
170.2×111.2mm
ET075EPT02
Get A Quote
7.5" High Brightness Display
1200×1200
MIPI
1000
-20~70°C
142.56×148.14mm
ET076SQ01-GX
Get A Quote
7.5" High Brightness Display
800×800
MIPI
850
-20~70°C
142.52×148.2mm
ET075SQ01-KDT
Get A Quote
7.6" High Brightness Display
800×800
MIPI
1000
-20~70°C
142.5×148mm
ET076SQ01
Get A Quote
7.8" High Brightness Display
400×1280
MIPI
700
-20~70°C
67.14×205.12mm
ET078HD01-T
Get A Quote
7.8" High Brightness Display
400×1280
LVDS
700
-20~70°C
67.14×205.12mm
ET078HD02-T
Get A Quote
7.8" High Brightness Display
400×1280
TTL
700
-20~70°C
67.8×205.78mm
ET070HD03-T
Get A Quote
8" High Brightness Display
800×1280
MIPI
800
-20~60°C
114.6×184.1mm
ET080WX01-H
Get A Quote
8" High Brightness Display
1024×600
LVDS
1000
-20~70°C
216×139mm
ET080WS01-HT
Get A Quote
8" High Brightness Display
1280×720
LVDS
750
-30~85°C
192.9×117mm
ET080HD01-AM
Get A Quote
8" High Brightness Display
1280×800
LVDS
700
-20~70°C
181.25×118.75mm
ET080WX01-AM
Get A Quote
8" High Brightness Display
1280×800
LVDS
700
-20~70°C
197.1×131.9mm
ET080WX01-AMT
Get A Quote
8" High Brightness Display
800×480
LVDS
900
-30~85°C
187.4×118mm
ET080WV01-W
Get A Quote
8" High Brightness Display
800×600
TTL
1000
-10~60°C
183×141mm
ET080HB01-EXT
Get A Quote
8" High Brightness Display
1920×1200
LVDS
1000
-20~70°C
181.7×119.8mm
ET080WU11-TT
Get A Quote
8" High Brightness Display
1920×1200
LVDS
2000
-30~85°C
179×119mm
ET080WWV-R1
Get A Quote
8" High Brightness Display
1200×1920
MIPI
700
-10~50°C
114.6×184.1mm
ET080WU01-AM
Get A Quote
8" High Brightness Display
1024×768
LVDS
800
-10~80°C
183.2×141.09mm
ET080XG01-KDT
Get A Quote
8" High Brightness Display
1200×1920
MIPI
1100
0~50°C
119.41×184.84mm
ET080WU05-OT
Get A Quote
8" High Brightness Display
1024×768
TTL
1000
-20~70°C
183×141mm
ET080XG01-V
Get A Quote
8" High Brightness Display
800×600
TTL
1000
-20~70°C
186×141mm
ET080WV01-ZK
Get A Quote
8" High Brightness Display
1024×600
LVDS
1500
-30~80°C
192.8×116.9mm
ET080WS01-Z1
Get A Quote
8.4" High Brightness Display
1024×768
LVDS
800
-30~80°C
199.5×149mm
ET084WX01-R
Get A Quote
8.8" High Brightness Display
768×768
LVDS
1000
-20~70°C
179.4×179.6mm
ET088SQ01-DB
Get A Quote
8.8" High Brightness Display
1280×320
LVDS
1000
-20~70°C
229.66×67.5mm
ET088BA01-KDT
Get A Quote
8.8" High Brightness Display
1920×480
MIPI
800
-20~70°C
231.3×64.3mm
ET088BA01-Z
Get A Quote
9" High Brightness Display
1280×720
LVDS
800
-20~70°C
242.6×150.2mm
ET090WX01-KDT
Get A Quote
9" High Brightness Display
1024×600
LVDS
1000
-20~70°C
210.7×126.5mm
ET090WS01-KDT
Get A Quote
9.2" High Brightness Display
1280×320
LVDS
3500
-30~80°C
238.63×69.5mm
ET092BA01-TVz
Get A Quote
9.2" High Brightness Display
1920×384
LVDS
3000
-30~85°C
239.45×59.24mm
ET092BA01-TS
Get A Quote
9.3" High Brightness Display
600×1600
MIPI
750
-20~70°C
89×231mm
ET093HD01-GX
Get A Quote
9.4" High Brightness Display
440×1920
MIPI
1000
-20~70°C
64.48×246.15mm
ET093BA03-T
Get A Quote
9.4" High Brightness Display
1024×400
TTL
800
-10~55°C
233.95×100mm
ET094BA01-KN
Get A Quote
9.7" High Brightness Display
1024×768
LVDS
1000
-10~50°C
210.2×164.2mm
ET097WX01-V
Get A Quote
10.1" High Brightness Display
1024×600
TTL
700
-20~70°C
252×150mm
ET101WS06-TT
Get A Quote
10.1" High Brightness Display
800×1280
HDMI
800
-20~70°C
159×244.6mm
ET101WX05-TT-HDMI
Get A Quote
10.1" High Brightness Display
1920×1080
HDMI
1000
-20~70°C
260×160mm
ET101HD01-KDT-HDMI
Get A Quote
10.1" High Brightness Display
1920×1080
LVDS
1200
-30~85°C
236×142.1mm
ET101FH01-R
Get A Quote
10.1" High Brightness Display
1280×800
HDMI
800
-20~70°C
229.46×149.16mm
ET101WX01-KDT-HDMI
Get A Quote
10.1" High Brightness Display
1280×800
LVDS
1000
-20~70°C
229.1×148.9mm
ET101WX08-T
Get A Quote
10.1" High Brightness Display
1200×1920
MIPI
900
-10~60°C
143×228mm
ET101WU13-TT
Get A Quote
10.1" High Brightness Display
1200×1920
MIPI
2000
-10~60°C
159.96×241.18mm
ET101WU16-TT
Get A Quote
10.1" High Brightness Display
1920×1200
LVDS
1000
-20~70°C
229.1×148.9mm
ET101WU15-TT
Get A Quote
10.1" High Brightness Display
1920×1200
LVDS
1100
-20~70°C
229.4×150.5mm
ET101WU14-O
Get A Quote
10.1" High Brightness Display
1920×1200
MIPI
2000
-20~80°C
229.46×149.1mm
ET101WU01-R
Get A Quote
10.1" High Brightness Display
1920×1200
MIPI
750
-40~70°C
238.1×159.19mm
ET101WU01-YT
Get A Quote
10.1" High Brightness Display
1024×600
LVDS
1100
-20~70°C
235×143mm
ET101WS01-ZK
Get A Quote
10.2" High Brightness Display
1920×720
LVDS
1000
-40~85°C
258.9×111.1mm
ET103BA02-T
Get A Quote
10.2" High Brightness Display
1280×480
LVDS
1000
-40~85°C
258.6×107mm
ET103BA01-H
Get A Quote
10.2" High Brightness Display
960×544
SPI
1500
0~40°C
224×157mm
ET102EP01
Get A Quote
10.4" High Brightness Display
1024×768
LVDS
800
-30~80°C
225.8×174.3mm
ET104WX01-KNT
Get A Quote
10.4" High Brightness Display
1024×100
TTL
950
-10~60°C
274.92×41.5mm
ET104BA01-ZK
Get A Quote
10.4" High Brightness Display
1024×768
LVDS
1200
-30~80°C
238.6×175.8mm
ET104WX01-AM
Get A Quote
10.4" High Brightness Display
640×480
LVDS
1500
-20~70°C
230×180.2mm
ET104VG01-H
Get A Quote
10.4" High Brightness Display
640×480
LVDS
900
-30~85°C
241×180.2mm
ET104VG01-ST
Get A Quote
10.5" High Brightness Display
1920×720
LVDS
850
-20~70°C
323.4×129.37mm
ET105BA01-ZT
Get A Quote
11.3" High Brightness Display
440×1920
MIPI
950
-20~70°C
64.98×266.39mm
ET113BA02-T
Get A Quote
11.6" High Brightness Display
1920×1080
eDP
1250
-20~70°C
268×158mm
ET116FH01-R
Get A Quote
11.6" High Brightness Display
1920×1080
eDP
900
-20~70°C
267.02×163.72mm
ET116FH02-TT
Get A Quote
11.6" High Brightness Display
1920×1080
eDP
1000
-20~70°C
267.02×163.72mm
ET116FH02-T
Get A Quote
11.8" High Brightness Display
1200×1600
LVDS
750
-30~85°C
194×258.55mm
ET118WU01-F
Get A Quote
12.1" High Brightness Display
1280×800
LVDS
1000
-30~80°C
283×185.1mm
ET121WX01-R
Get A Quote
12.1" High Brightness Display
1280×800
LVDS
700
-20~70°C
293.66×198.66mm
ET121WX02-TT
Get A Quote
12.1" High Brightness Display
1024×768
LVDS
900
-20~70°C
286.5×225mm
ET121WX01-HT
Get A Quote
12.1" High Brightness Display
1024×768
LVDS
1500
-30~85°C
260.5×204mm
ET121WX02-R
Get A Quote
12.1" High Brightness Display
800×600
LVDS
2000
-30~80°C
260.5×204mm
ET121DH01-H
Get A Quote
12.3" High Brightness Display
1920×720
LVDS
1200
-30~80°C
310×128mm
ET123BA20-T
Get A Quote
12.8" High Brightness Display
1920×1080
LVDS
1100
-30~85°C
294.4×175mm
ET128FH01-KD
Get A Quote
12.9" High Brightness Display
1200×1920
MIPI
700
-20~70°C
190.3×291.2mm
ET129BA01-GLT
Get A Quote
13.3" High Brightness Display
3840×2160
eDP
2000
0~50°C
313×189.5mm
ET133UH01-R
Get A Quote
13.3" High Brightness Display
1920×1080
LVDS
1000
-20~70°C
309.7×184.1mm
ET133FH01-R
Get A Quote
13.3" High Brightness Display
1920×1080
eDP
1000
-20~70°C
308×183.45mm
ET133FH03-TT
Get A Quote
13.3" High Brightness Display
1920×1080
TTL
1000
-20~70°C
306.2×190.62mm
ET133FH01-TST
Get A Quote
13.5" High Brightness Display
1280×235
LVDS
1000
0~50°C
360×83mm
ET135BA01-G
Get A Quote
14" High Brightness Display
1920×1080
eDP
1000
-30~80°C
317.52×186.76mm
ET140FH01-HG
Get A Quote
14.1" High Brightness Display
3840×1100
LVDS
1000
0~60°C
350.52×118.65mm
ET141BA01-R
Get A Quote
14.5" High Brightness Display
2560×720
LVDS
750
-20~70°C
363.5×133.5mm
ET145BA01-K
Get A Quote
14.9" High Brightness Display
1024×273
LVDS
700
0~50°C
399.78×81mm
ET149BA01-R
Get A Quote
15" High Brightness Display
1600×1200
LVDS
1050
-30~70°C
318.7×242.65mm
ET150WU01-LP
Get A Quote
15" High Brightness Display
1024×768
LVDS
1000
-20~70°C
37.4×231.3mm
ET150WX01-R
Get A Quote
15" High Brightness Display
1024×768
LVDS
1000
-30~85°C
326.5×253.5mm
ET150WX01-ZKT
Get A Quote
15" High Brightness Display
1920×720
LVDS
1200
-30~85°C
366.88×146.28mm
ET150BA01-GL
Get A Quote
15.3" High Brightness Display
1280×370
LVDS
700
0~50°C
396×124mm
ET153BA01-R
Get A Quote
15.6" High Brightness Display
1920×1080
LVDS
2000
-20~80°C
359.5×206.74mm
ET156FH01-R
Get A Quote
15.6" High Brightness Display
1920×1080
LVDS
1000
-20~70°C
360×212.3mm
ET156FH06-T
Get A Quote
15.6" High Brightness Display
1366×768mm
LVDS
2000
0~60°C
363.8×215.9mm
ET156XW01-V
Get A Quote
15.6" High Brightness Display
1920×1080
eDP
1000
-30~80°C
360×222.45mm
ET156FH01-ZKT
Get A Quote
15.7" High Brightness Display
960×960
LVDS
700
-20~60°C
452.95×452.95mm
ET157CR01-V
Get A Quote
16" High Brightness Display
1280×512
LVDS
1000
0~50°C
396×173.6mm
ET160BA01-Y
Get A Quote
16.8" High Brightness Display
1366×378
LVDS
800
0~50°C
430.37×137.6mm
ET168BA01-RX
Get A Quote
17" High Brightness Display
1280×1024
LVDS
1000
-30~85°C
358.5×296.5mm
ET170SX01-ZKT
Get A Quote
17" High Brightness Display
1920×1200
LVDS
1000
-20~80°C
382.3×247.5mm
ET170WU01-Z
Get A Quote
17.3" High Brightness Display
1920×1080
LVDS
1500
-20~60°C
403×240mm
ET173FH01-HT
Get A Quote
17.3" High Brightness Display
1920×1080
eDP
1000
-20~70°C
389.95×227.07mm
ET173FH01-HG
Get A Quote
17.3" High Brightness Display
3840×2160
eDP
1500
0~50°C
414.85×268mm
ET173UH01-H
Get A Quote
18.5" High Brightness Display
1366×768
LVDS
2500
-10~60°C
430×254mm
ET185XW01-H
Get A Quote
18.5" High Brightness Display
3840×2160
eDP
700
0~50°C
422.2×244.1mm
ET185UH01-R
Get A Quote
18.5" High Brightness Display
1920×1080
LVDS
1000
-20~70°C
418.02×243.9mm
ET185FH02-T
Get A Quote
18.5" High Brightness Display
1920×1080
LVDS
1000
-30~80°C
430.4×254.6mm
ET185FH21-K
Get A Quote
18.5" High Brightness Display
1200×1200
LVDS
700
0~50°C
366×361.5mm
ET185SQ01-V
Get A Quote
18.5" High Brightness Display
1366×768
HDMI
1000
0~50°C
430.4×254.6mm
ET185XW01-R-HDMI
Get A Quote
19" High Brightness Display
1440×900
LVDS
1200
-10~50°C
428×278mm
ET190BA01-H
Get A Quote
19" High Brightness Display
1920×320
LVDS
1500
0~50°C
500×119.6mm
ET190BA01-T
Get A Quote
19" High Brightness Display
1280×1024
LVDS
2000
-30~85°C
396×324mm
ET190SX01-HT
Get A Quote
19" High Brightness Display
1920×290
LVDS
700
0~50°C
482×73mm
ET190BA01-Y
Get A Quote
19.1" High Brightness Display
1920×388
LVDS
700
0~50°C
495.6×121.3mm
ET191BA01-R
Get A Quote
19.1" High Brightness Display
1920×360
LVDS
1500
0~50°C
510×123mm
ET191BA02-R
Get A Quote
19.5" High Brightness Display
1920×540
LVDS
1500
-30~80°C
497.4×158.4mm
ET195BA01-RS
Get A Quote
19.7" High Brightness Display
1920×624
LVDS
700
-20~70°C
497.4×179.4mm
ET197BA01-R
Get A Quote
21.5" High Brightness Display
1920×1080
LVDS
2500
-20~70°C
495.2×291.5mm
ET215FH01-R
Get A Quote
22" High Brightness Display
1920×710
LVDS
1000
0~50°C
548.4×222.2mm
ET220BA01-R
Get A Quote
23.6" High Brightness Display
848×848
LVDS
700
0~50°C
661.184×661.184mm
ET236SQ01-V
Get A Quote
23.6" High Brightness Display
1280×1280
LVDS
1500
0~50°C
657×657mm
ET236SQ01-A
Get A Quote
23.8" High Brightness Display
1920×1080
LVDS
2000
-20~80°C
550.46×325.0mm
ET238FH01-R
Get A Quote
23.8" High Brightness Display
3840×2160
eDP
1300
0~50°C
550.46×325.04mm
ET238UH01-R
Get A Quote
23.8" High Brightness Display
3840×2160
eDP
1300
0~50°C
550.46×325.04mm
ET238UH01-R
Get A Quote
23.8" High Brightness Display
1920×1080
LVDS
1100
0~50°C
544.8×320.5mm
ET238FH01-Z
Get A Quote
25" High Brightness Display
1366×254
LVDS
700
0~50°C
735.4×170.5mm
ET250BA01-YF
Get A Quote
27" High Brightness Display
1920×1080
LVDS
2000
-20~70°C
618×360mm
ET270FH01-R
Get A Quote
27" High Brightness Display
2560×1440
LVDS
1500
0~50°C
608.8×355.13mm
ET270WH01-R
Get A Quote
27" High Brightness Display
1920×1080
LVDS
2000
-20~70°C
618×360mm
ET270FH01-R
Get A Quote
27" High Brightness Display
3840×2160
LVDS
1500
0~50°C
618×360mm
ET270UH01-R
Get A Quote
27" High Brightness Display
3840×2160
eDP
1000
0~50°C
628.8×367.1mm
ET270UH02-R
Get A Quote
28" High Brightness Display
1366×232
LVDS
700
0~50°C
729.5×160mm
ET280BA01-RX
Get A Quote
28" High Brightness Display
1920×360
LVDS
2000
-30~80°C
736.2×157.5mm
ET280BA01-RS
Get A Quote
28" High Brightness Display
1920×400
LVDS
1000
0~50°C
735.5×179.1mm
ET280BA01-Z
Get A Quote
28.5" High Brightness Display
1366×384
LVDS
2000
0~50°C
730×231mm
ET285BA01-I
Get A Quote
28.6" High Brightness Display
1920×540
LVDS
1500
0~50°C
720.8×226.3mm
ET286BA01-F
Get A Quote
29" High Brightness Display
1920×624
LVDS
2000
-20~70°C
735×266mm
ET290BA01-Y
Get A Quote
29.3" High Brightness Display
1920×710
LVDS
1000
0~50°C
735.4×298.9mm
ET293BA01-Y
Get A Quote
29.4" High Brightness Display
1920×720
LVDS
2000
0~50°C
730.4×293.9mm
ET294BA01-I
Get A Quote
32" High Brightness Display
1920×1080
LVDS
1000
-20~70°C
725.2×422.7mm
ET320FH01-T
Get A Quote
32" High Brightness Display
3840×2160
eDP
1500
0~50°C
709.4×412mm
ET320UH01-Z
Get A Quote
Ultra High Brightness Displays

Ultra High Brightness Displays are screens designed to offer exceptionally high levels of brightness, typically exceeding 1,000 nits (the standard for regular high-brightness displays). These displays are engineered to remain visible even in extremely bright environments, such as direct sunlight or highly-lit indoor spaces, making them ideal for outdoor digital signage, public displays, and professional applications where visibility is critical.

Key Features of Ultra High Brightness Displays:

Brightness (Nits)
Ultra high brightness displays typically have brightness levels of 1,500 nits to 5,000 nits, though some specialized displays can reach up to 10,000 nits or more. For reference, standard LCD screens usually have a brightness range between 200-400 nits, and high-brightness displays are around 800-1,000 nits. Ultra high brightness ensures that content remains clearly visible even under intense direct sunlight.

Enhanced Visibility in Bright Environments
The key benefit of ultra high brightness is visibility. Whether in outdoor environments, stadiums, or even places like airports or shopping malls, these displays are capable of cutting through ambient light and ensuring the content is legible and vibrant.

Anti-Glare and Anti-Reflective Coatings
To further improve visibility, ultra high brightness displays often come with anti-glare or anti-reflective coatings. This reduces reflections and helps to prevent the "mirror effect" where surrounding light obscures the content.

Improved Contrast and Color
Ultra high brightness displays tend to have higher contrast ratios, helping to ensure that the brightest whites and the darkest blacks are clearly visible, even in bright conditions. In many cases, they also offer better color accuracy and saturation, which is crucial for applications like advertising or media.

Robustness for Outdoor Use
These displays are typically built to withstand outdoor environments. They often feature IP ratings (Ingress Protection) that ensure protection against dust, rain, and harsh weather conditions. They may also have UV-resistant screens and be designed to work in extreme temperatures, both hot and cold.

Longer Lifespan
With higher brightness comes a greater demand on the display's components, so ultra high brightness displays are often built with enhanced durability. These displays are designed to maintain their brightness over a long period of time without significant degradation, making them more suitable for continuous use in outdoor environments.

Energy Consumption
The high brightness levels typically result in higher energy consumption, which can affect power management and battery life in portable applications. However, advances in technology are making these displays more power-efficient without compromising on performance.

Fan or Liquid Cooling Systems
To manage the heat generated by high brightness levels, many ultra high brightness displays come with integrated cooling systems. These may include fans or liquid cooling mechanisms to keep the display functioning at optimal temperatures, especially in outdoor environments.

Applications of Ultra High Brightness Displays

Outdoor Digital Signage
These displays are commonly used in digital billboards, advertising screens, and information kiosks in public spaces like shopping malls, train stations, and airports. They can handle the high ambient light levels found in outdoor settings, ensuring that advertisements, directions, or announcements are clearly visible.

Stadiums and Arenas
Ultra high brightness displays are often deployed in stadiums or arenas where large screens are needed to display game scores, live feeds, or advertisements to crowds in outdoor or brightly-lit environments.

Retail and Public Displays
Stores, shopping centers, and public spaces often use ultra high brightness displays to attract attention to promotions or information. These screens need to be highly visible even in areas with lots of natural light.

Transportation
In transportation hubs such as airports, train stations, and bus terminals, ultra high brightness displays are used to provide departure times, gate information, or advertisements. These displays need to be readable from a distance and under varying light conditions.

Automotive and Vehicle Displays
Some automotive dashboards, especially in high-end or commercial vehicles, use ultra high brightness displays to ensure that important driving information remains visible under direct sunlight. These displays also help with navigation and infotainment systems

Outdoor Public Events
At outdoor concerts, festivals, or public events, ultra high brightness displays are used to display real-time information, live streaming video, or advertisements. The displays must be capable of handling daylight conditions while being large enough to be seen from a distance.

Military and Aerospace Applications
Military and aerospace environments require ultra high brightness displays for control panels, aircraft cockpits, or field operations. These displays need to operate in extreme conditions, including bright sunlight, dust, and high temperatures.

Medical and Healthcare Environments
In certain healthcare settings, especially those where screens are exposed to natural light (like in surgical suites or outdoor medical equipment), ultra high brightness displays can ensure clear visibility for real-time monitoring and data visualization.

Surveillance and Security Systems
Ultra high brightness displays can be used in security or surveillance control rooms, where monitoring screens need to be visible in both dark and brightly lit conditions.

Interactive Displays in Museums and Exhibitions
Museums, galleries, and exhibitions that use interactive screens often require ultra high brightness displays to ensure visibility in bright environments while maintaining an engaging user experience.

Types of Ultra High Brightness Displays

LED (Light Emitting Diode) Displays
Most ultra high brightness displays use LED technology due to its ability to produce high brightness levels efficiently. Direct LED or edge-lit LED configurations are commonly used in large-format screens. LED displays are popular in outdoor and public applications due to their brightness, color quality, and energy efficiency.

LCD (Liquid Crystal Display)
While traditional LCDs require a backlight, some high-brightness LCDs are engineered with powerful backlight systems, including Full Array Local Dimming (FALD), to achieve ultra high brightness. These are typically used in places where high resolution and color accuracy are also important.

OLED (Organic Light Emitting Diode)
OLED displays can reach high brightness levels as well, but they are typically more expensive and used for smaller, high-end applications. OLED technology offers deep blacks and high contrast, but high-brightness OLED displays are less common than LED-based solutions for outdoor use due to their higher power consumption.

E-Ink Displays
Some E-Ink displays, used in applications like electronic signage or e-readers, are engineered for readability in bright sunlight. Though not typically classified under "ultra high brightness" (since they reflect ambient light), they still perform exceptionally well in direct sunlight and are ultra-readable in bright conditions.

Conclusion:

Ultra high brightness displays are essential for environments where visibility is paramount, such as outdoor digital signage, advertising, and public information displays. These displays excel in bright or direct sunlight, providing superior clarity and legibility. They often come with features like anti-glare coatings, improved durability, and cooling systems to ensure optimal performance in challenging conditions.

Ultra High Brightness Displays Solutions for Diverse Applications

Brightness from 0-3000 for perfect display effect achievement. 100% NTSC makes the vividness of the picture better and the color transition in the picture more natural.

Color Temperature is positive white at around 5500K, warm white (yellowish) at 3500K and also cool white (cold) at 6500K.

Driver circuit with sufficient voltage and current values to meet output requirements and reduce the secondary development cycle. Heat dissipation for high-brightness products to advance design of reasonable heat dissipation structure.

Power consumption, we increase the brightness without increasing the power consumption.

Cables, Backlighting also requires cables, either through an FPC connected to the LCD's FPC and controlled through a port, or a separate cable that controls it through a connector.LED life reached the standard of 30K hours Min. 50K, 70K, 100K hours are all achievable.
 Ultra High Brightness Displays Touch screen,standard type and customization

Ultra High Brightness Displays Driver board/adapter board, standard type and design customization

DEMO board, H-DMl board, other customized board, etc.

 Ultra High Brightness Displays Embedded Integrated Solution

UART display solution, H-DMl display solution, Window display solution, Android display solution, Raspberry Pi solution, portable secondary screen solution, etc.

Get in Touch:

Design ingenuity. Manufacturing agility and scale. Supply chain innovation.
No matter how complex or demanding the project, we're helping today's technology innovators solve it.
Get started with a trusted partner...
Name*
Job title
Companu name
Email*
Phone
Message
Get in touch Contact Us
Eurotech is a worldwide leading display technology company focused on advanced innovative visual technology systems in high-growth markets, with deep understanding of the needs of the modern technology world..
Follow Us:

Links

Contact us

Tel:(852) 6942 7360
Tel:(86) 755 8395 2292
E-mail:lcdsource@eurotech-lcd.com
E-mail:info@eurotech-ic.com
ShenZhen office:Building A, Jinfeng Zhihui Valley, No. 45, Yonghe Road, Bao'an District,Shenzhen
HK office:Unit 1003-1004,10/F, Block4, Nam Fung Industrial City, 18 Tin Hau Road,Tuen Mun, HONGKONG
For Blog Updates

Subscribe to get the latest relevant information.Fill in your info.
© Eurotech All Rights Reserved
