An LCD controller (also called an LCD display controller) is the interface chip or circuit that manages communication between the host system (like a microcontroller, GPU, or CPU) and the LCD panel.
Since a raw LCD panel can’t show images by itself—it only has rows and columns of liquid crystal cells (pixels) that need precise voltage signals—an LCD controller provides the necessary logic and timing to make the panel work properly.
Key Functions of an LCD Controller
Signal Conversion
Translates digital image data (RGB, LVDS, MIPI, HDMI, etc.) from the host into the format the LCD panel understands.
Timing Control
Generates synchronization signals (HSYNC, VSYNC, DOTCLK, DE) to scan each pixel row and column in the correct sequence.
Frame Buffering (in some controllers)
Stores image data in RAM so the LCD doesn’t need constant data refreshing from the host.
Useful for microcontrollers with limited memory.
Voltage/Driving Control
Provides correct voltage waveforms to drive the LCD pixels without causing flicker or ghosting.
Touch & Backlight Integration (in advanced controllers)
Some also integrate capacitive/resistive touch controllers.
Control LED backlight brightness via PWM.
Types of LCD Controllers
Integrated LCD controller in MCU/SoC
Many modern microcontrollers (like STM32, i.MX, or ESP32-S3) have built-in LCD controllers.
External LCD controller ICs
Used when the MCU/GPU cannot directly drive the LCD panel. Examples: RA8875, SSD1963, ILI9341.
Bridge/Scaler Controllers
Convert signals (e.g., HDMI → LVDS, MIPI → RGB).
Example in Practice
A TFT LCD panel usually requires an LCD controller (built-in or external).
A character LCD (like 16x2) usually has its own onboard controller (like HD44780) that simplifies driving for microcontrollers.
In short:
An LCD controller is the "translator and manager" that ensures your digital device can correctly send image data to an LCD display, handling timing, voltage, and communication details.
