LP140WUA-SPB1 14 Inch TFT LCD Display eDP 1920×1200 LCD Display With In-Cell Touch

Enabling Customer Innovation to Empower Tomorrow's Technology

Home > Technologies > LG Display > LP140WUA-SPB1

LP140WUA-SPB1 is a 14.0 inch diagonal a-Si TFT-LCD display screen product from LG Display, with a built-in WLED backlight, With LED Driver, touchscreen In-Cell Touch. LP140WUA-SPB1 supports display 1920(RGB)×1200 (WUXGA) with aspect ratio of 16:10 (W:H), whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 301.594(W)×188.496(H) mm, outline size of 306.59(W)×198.4(H)×5.25(D) mm, with surface treament of Antiglare, Hard coating (3H), net weight of 320g (Max.), shape stype of Slim (PCBA Bent, T≤3.0mm). As a IPS, Normally Black, Transmissive LCM product, LP140WUA-SPB1 can provides 300 cd/m² display brightness 800:1 transimissive contrast ratio, 80/80/80/80 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 30 (Typ.)(Tr+Td) ms. Gray scale or the brightness of the sub-pixel is determined with a 6-bit + Hi-FRC gray scale signal for each dot, thus presenting a palette of 16.7M colors, also with performance of color gamut 72% (NTSC). This product adopted WLED as it's backlight systerm which was placed as Edge light type and have a working life time of 15K hours, With LED Driver. LP140WUA-SPB1 utilizes eDP (2 Lanes) as it's signal inputting systerm, which connected by 40 pins Connector with power supply voltage of 3.3V (Typ.). It's typical vertical frame rate (Fv) is 60Hz.

Technical Data:

Part #：

LP140WUA-SPB1

Brand：

LG Display

Size：

14 inch"

Resolution：

1920x1200

Interface：

eDP (2 Lanes)

Technology：

Transmissive

Brightness：

300cd/m²

Operating Tem：

0~50°C

Storage Tem：

-20~60°C
