AMS881KB01 8.8 Inch AMOLED Display eDP 1920×1200 OLED Display With On-Cell Touch

Enabling Customer Innovation to Empower Tomorrow's Technology
Home > Technologies > Samsung > AMS881KB01
AMS881KB01 is a 8.8 inch diagonal AM-OLED display screen product, it self emiting, touchscreen On-Cell Touch. AMS881KB01 supports display 1920(RGB)×1200 (WUXGA) with aspect ratio of 16:10 (W:H), whose pixels are arranged in S-Stripe RGB, according to calculation of Panelook it's pixel density is 257 PPI. As for mechanical detail, it features active area of 189.696(W)×118.56(H) mm, outline size of 200(W)×131.9(H) mm, with surface treament of Anti Fingerprint, net weight of 106g (Max.). AMS881KB01 can provides 475 cd/m² display brightness 1000000:1 transimissive contrast ratio, 85/85/85/85 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 1 (Typ.)(Tr+Td) ms. Gray scale or the brightness of the sub-pixel is determined with a 10-bit gray scale signal for each dot, thus presenting a palette of 1.07B colors, also with performance of color gamut 100% (DCI-P3). This product emiting itself . AMS881KB01 utilizes eDP (2 Lanes) as it's signal inputting systerm, which connected by 40 pins Connector with power supply voltage of 3.3/10V (Typ.)(VDD/VBAT). It's typical vertical frame rate (Fv) is 144Hz.
Technical Data:
Part #：
AMS881KB01
Brand：
Samsung
Size：
8.8 inch"
Resolution：
1920x1200
Interface：
eDP (2 Lanes)
Technology：
AM-OLED
Brightness：
475cd/m²
Operating Tem：
-20~70°C
Storage Tem：
-40~85°C
Contact Us
Name
Email
Telephone
Touch screen customize:
Cover Glass customize:
Demo Kits:
Message
Integrated Display solutions
Touch screen, standard ready-made and customization
Supportrting capacitive touch screen (I2C interface, SPI interface, USB interface, UART interface)/ resistive touch screen / touch structure and function customization / optical bonding manufacturing.
Specific features:
High cost effective, automotive grade, industrial grade, medical grade solutions.
Durable and sturdy design for extreme environments.
Supports glove touch, multi touch, and stylus touch.
Featuring waterproofing, salt water resistance, low reflectivity, and 3D gesture touch control .
Driver board/adapter board, standard ready-made and design customization
DEMO board, HDMI board, other customized board, etc
Embbed Integrated Solution
UART display solution, HMI display solution, WINDOW display solution, Android display solution, Raspberry Pi solution, portable secondary screen solution, etc.
