Electric Vehicle Charging Display


Enabling Customer Innovation to Empower Tomorrow's Technology
Home > Industries > Electric Vehicle Charging Display

EUROTECH Electric Vehicle Charging Display Solutions

Electric Vehicle Charging Display Solutions
Custom High-Brightness Touch Displays for Smart EV Charging Infrastructure


As electric vehicle adoption accelerates worldwide, charging stations are evolving into intelligent, connected user interfaces that require reliable, sunlight-readable and highly durable display solutions. Eurotech specializes in the design, engineering, integration, and manufacturing of high-performance Electric Vehicle Charging Displays tailored for public charging stations, DC fast chargers, AC wall chargers, fleet charging systems, and next-generation smart energy networks.

Eurotech EV charging display solutions combine high-brightness TFT LCD technology, projected capacitive touchscreens, optical bonding, rugged cover glass, embedded controller integration, and custom mainboard development to deliver exceptional performance in demanding outdoor environments.

Size
Resolution
Interface
Brightness
Operating Temp.
Outline Dim.
Model
Datasheet/Quote
Size: 3.5" Electric Vehicle Charging Display
Resolution: 800×640
Interface: TTL
Brightness: 1500
Operating Temp.: -20~70°C
Outline Dim.: 97x83mm
Model: ET035CR10-TRT
Get A Quote
Size: 3.5" Electric Vehicle Charging Display
Resolution: 640×480
Interface: MIPI
Brightness: 750
Operating Temp.: -20~70°C
Outline Dim.: 94.08×74.8mm
Model: ET035VG01-H
Get A Quote
Size: 3.5" Electric Vehicle Charging Display
Resolution: 480×640
Interface: MIPI
Brightness: 900
Operating Temp.: -20~70°C
Outline Dim.: 61×81.75mm
Model: COM35H3P70ULC
Get A Quote
Size: 4.3" Electric Vehicle Charging Display
Resolution: 480×272
Interface: TTL
Brightness: 1100
Operating Temp.: -20~70°C
Outline Dim.: 105.5×67.2mm
Model: COM43H4P09UTC
Get A Quote
Size: 4.3" Electric Vehicle Charging Display
Resolution: 480×800
Interface: TTL
Brightness: 800
Operating Temp.: -30~85°C
Outline Dim.: 62×104.25mm
Model: ET043WV09-TT
Get A Quote
Size: 4.3" Electric Vehicle Charging Display
Resolution: 480×272
Interface: TTL
Brightness: 1200
Operating Temp.: -30~85°C
Outline Dim.: 105.5×67.2mm
Model: COM43H4N44ULC
Get A Quote
Size: 5" Electric Vehicle Charging Display
Resolution: 800×480
Interface: LVDS
Brightness: 1200
Operating Temp.: -30~85°C
Outline Dim.: 124×80.82mm
Model: COM50H5N15ULC
Get A Quote
Size: 5" Electric Vehicle Charging Display
Resolution: 800×480
Interface: TTL
Brightness: 1100
Operating Temp.: -30~85°C
Outline Dim.: 165.4×104.59mm
Model: ET070WV06-KT
Get A Quote
Size: 5" Electric Vehicle Charging Display
Resolution: 480×854
Interface: TTL
Brightness: 1000
Operating Temp.: -20~70°C
Outline Dim.: 66.4×120.05mm
Model: ET050FW0-H
Get A Quote
Size: 5" Electric Vehicle Charging Display
Resolution: 720×1280
Interface: MIPI
Brightness: 950
Operating Temp.: -20~70°C
Outline Dim.: 70.01×116.29mm
Model: ET050HD01-A
Get A Quote
Size: 5" Electric Vehicle Charging Display
Resolution: 720×1280
Interface: MIPI
Brightness: 1000
Operating Temp.: -20~70°C
Outline Dim.: 66.4×120.05mm
Model: ET050FH01-X
Get A Quote
Size: 5" Electric Vehicle Charging Display
Resolution: 1080×1920
Interface: MIPI
Brightness: 1200
Operating Temp.: -20~70°C
Outline Dim.: 64×118mm
Model: ET050FH10-T
Get A Quote
Size: 5" Electric Vehicle Charging Display
Resolution: 800×480
Interface: TTL
Brightness: 1000
Operating Temp.: -30~85°C
Outline Dim.: 121.3×78.8mm
Model: A0500WVF2MAAA
Get A Quote
Size: 5" Electric Vehicle Charging Display
Resolution: 800×480
Interface: LVDS
Brightness: 1200
Operating Temp.: -30~85°C
Outline Dim.: 124×80.82mm
Model: COM50H5N25ULC
Get A Quote
Size: 5" Electric Vehicle Charging Display
Resolution: 800×480
Interface: TTL
Brightness: 1000
Operating Temp.: -30~85°C
Outline Dim.: 120.7×77.8mm
Model: TM050RDZG03-30
Get A Quote
Size: 5" Electric Vehicle Charging Display
Resolution: 800×480
Interface: TTL
Brightness: 1500
Operating Temp.: -30~85°C
Outline Dim.: 120.7×75.8mm
Model: ET050WV06-T
Get A Quote
Size: 5.5" Electric Vehicle Charging Display
Resolution: 1080×1920
Interface: MIPI
Brightness: 2000
Operating Temp.: -20~70°C
Outline Dim.: 83.7×141.2mm
Model: ET055WU06-TT
Get A Quote
Size: 5.5" Electric Vehicle Charging Display
Resolution: 480×960
Interface: TTL
Brightness: 1300
Operating Temp.: -20~70°C
Outline Dim.: 68×134mm
Model: ET055FW01-R
Get A Quote
Size: 5.5" Electric Vehicle Charging Display
Resolution: 720×1280
Interface: MIPI
Brightness: 1000
Operating Temp.: -20~70°C
Outline Dim.: 70.34×128.1mm
Model: ET055HD11-T
Get A Quote
Size: 6" Electric Vehicle Charging Display
Resolution: 1080×1920
Interface: MIPI
Brightness: 800
Operating Temp.: -20~70°C
Outline Dim.: 81×143mm
Model: ET060FH05-TT
Get A Quote
Size: 7" Electric Vehicle Charging Display
Resolution: 800×480
Interface: TTL
Brightness: 700
Operating Temp.: -20~70°C
Outline Dim.: 164×100mm
Model: ET070WV01-T
Get A Quote
Size: 7" Electric Vehicle Charging Display
Resolution: 800×480
Interface: LVDS
Brightness: 1000
Operating Temp.: -30~80°C
Outline Dim.: 169.8×109.7mm
Model: TCG070WVLQGPNN-AN40
Get A Quote
Size: 7" Electric Vehicle Charging Display
Resolution: 800×480
Interface: TTL
Brightness: 750
Operating Temp.: -30~85°C
Outline Dim.: 164.9×100mm
Model: DJ070NA-03J
Get A Quote
Size: 7" Electric Vehicle Charging Display
Resolution: 800×480
Interface: TTL
Brightness: 1000
Operating Temp.: -30~85°C
Outline Dim.: 164.9×100mm
Model: P0700WVN1MA00
Get A Quote
Size: 7" Electric Vehicle Charging Display
Resolution: 800×480
Interface: LVDS
Brightness: 800
Operating Temp.: -40~85°C
Outline Dim.: 167.7×109.45mm
Model: TX18D206VM0BAA
Get A Quote
Size: 7" Electric Vehicle Charging Display
Resolution: 800×480
Interface: LVDS
Brightness: 790
Operating Temp.: -30~85°C
Outline Dim.: 169.8×109.7mm
Model: COM70H7M24ULC
Get A Quote
Size: 7" Electric Vehicle Charging Display
Resolution: 800×480
Interface: TTL
Brightness: 700
Operating Temp.: -20~70°C
Outline Dim.: 164×100mm
Model: ET070WV01-T
Get A Quote
Size: 7" Electric Vehicle Charging Display
Resolution: 800×480
Interface: LVDS
Brightness: 1500
Operating Temp.: -30~85°C
Outline Dim.: 169.8×109.7mm
Model: P0700WVF1MA00
Get A Quote
Size: 7" Electric Vehicle Charging Display
Resolution: 1024×600
Interface: LVDS
Brightness: 1600
Operating Temp.: -30~85°C
Outline Dim.: 182×117.6mm
Model: ET070WS07-KT
Get A Quote
Size: 7" Electric Vehicle Charging Display
Resolution: 1200×1920
Interface: MIPI
Brightness: 1300
Operating Temp.: -20~70°C
Outline Dim.: 105.18×163.34mm
Model: ET070WU01-TT
Get A Quote
Size: 7" Electric Vehicle Charging Display
Resolution: 800×1280
Interface: MIPI
Brightness: 2000
Operating Temp.: -20~70°C
Outline Dim.: 115×176.7mm
Model: ET070WX30-TT
Get A Quote
Size: 7" Electric Vehicle Charging Display
Resolution: 1080×1920
Interface: MIPI
Brightness: 2000
Operating Temp.: -20~70°C
Outline Dim.: 102.5×175mm
Model: ET070FH01-RT
Get A Quote
Size: 7" Electric Vehicle Charging Display
Resolution: 800×480
Interface: LVDS
Brightness: 900
Operating Temp.: -30~80°C
Outline Dim.: 187.7×123.7mm
Model: COM70H7M44UTC
Get A Quote
Size: 7" Electric Vehicle Charging Display
Resolution: 1920×1080
Interface: LVDS
Brightness: 1200
Operating Temp.: -40~85°C
Outline Dim.: 169×104mm
Model: TX18D200VM0EAA
Get A Quote
Size: 7" Electric Vehicle Charging Display
Resolution: 800×480
Interface: LVDS
Brightness: 1000
Operating Temp.: -30~80°C
Outline Dim.: 170×110mm
Model: G070ACE-LH1
Get A Quote
Size: 7" Electric Vehicle Charging Display
Resolution: 800×480
Interface: LVDS
Brightness: 1000
Operating Temp.: -30~80°C
Outline Dim.: 169.8×109.7mm
Model: P0700WVF1MA10
Get A Quote
Size: 7" Electric Vehicle Charging Display
Resolution: 800×480
Interface: TTL
Brightness: 1000
Operating Temp.: -30~85°C
Outline Dim.: 164.9×100mm
Model: TM070RDHG34-00
Get A Quote
Size: 7" Electric Vehicle Charging Display
Resolution: 1024×600
Interface: TTL
Brightness: 1000
Operating Temp.: -30~80°C
Outline Dim.: 164.9×100mm
Model: ET070WS10-TC
Get A Quote
Size: 7" Electric Vehicle Charging Display
Resolution: 1280×768
Interface: LVDS
Brightness: 1250
Operating Temp.: -40~85°C
Outline Dim.: 207.785×118.496mm
Model: HSD070JWW1-A20-T00
Get A Quote
Size: 7" Electric Vehicle Charging Display
Resolution: 1920×1080
Interface: MIPI
Brightness: 4500
Operating Temp.: -20~70°C
Outline Dim.: 164.19×97.87mm
Model: ET070FH01-HTT
Get A Quote
Size: 7" Electric Vehicle Charging Display
Resolution: 1024×600
Interface: MIPI
Brightness: 1500
Operating Temp.: -20~70°C
Outline Dim.: 165x100mm
Model: ET070HD05-KT
Get A Quote
Size: 7" Electric Vehicle Charging Display
Resolution: 1280×768
Interface: LVDS
Brightness: 1500
Operating Temp.: -40~85°C
Outline Dim.: 164.4×105mm
Model: TX18D212VM0BAA
Get A Quote
Size: 8" Electric Vehicle Charging Display
Resolution: 800×480
Interface: LVDS
Brightness: 1200
Operating Temp.: -40~85°C
Outline Dim.: 190.8×120.5mm
Model: TX20D208VM0BAA
Get A Quote
Size: 8" Electric Vehicle Charging Display
Resolution: 800×480
Interface: LVDS
Brightness: 1500
Operating Temp.: -30~80°C
Outline Dim.: 189×122mm
Model: TX20D200VM2BAB
Get A Quote
Size: 8" Electric Vehicle Charging Display
Resolution: 1920×1200
Interface: LVDS
Brightness: 1000
Operating Temp.: -20~70°C
Outline Dim.: 181.7×119.8mm
Model: ET080WU11-TT
Get A Quote
Size: 8" Electric Vehicle Charging Display
Resolution: 800×1280
Interface: MIPI
Brightness: 800
Operating Temp.: -20~70°C
Outline Dim.: 121×194mm
Model: ET080WV30-TT
Get A Quote
Size: 8" Electric Vehicle Charging Display
Resolution: 800×480
Interface: LVDS
Brightness: 1300
Operating Temp.: -30~80°C
Outline Dim.: 200x124mm
Model: TX20D200VM2BVA
Get A Quote
Size: 8" Electric Vehicle Charging Display
Resolution: 1280×720
Interface: LVDS
Brightness: 700
Operating Temp.: -30~85°C
Outline Dim.: 200.6×127.4mm
Model: DD080IA-20A
Get A Quote
Size: 8" Electric Vehicle Charging Display
Resolution: 1280×720
Interface: LVDS
Brightness: 750
Operating Temp.: -30~85°C
Outline Dim.: 192.8×116.9mm
Model: DJ080IA-11A
Get A Quote
Size: 8" Electric Vehicle Charging Display
Resolution: 800×600
Interface: TTL
Brightness: 700
Operating Temp.: -20~70°C
Outline Dim.: 183×141mm
Model: TM080SDHG02-41
Get A Quote
Size: 8" Electric Vehicle Charging Display
Resolution: 800×480
Interface: TTL
Brightness: 840
Operating Temp.: -40~85°C
Outline Dim.: 185.7×119.6mm
Model: AV080WVM-N15
Get A Quote
Size: 8" Electric Vehicle Charging Display
Resolution: 800×480
Interface: LVDS
Brightness: 1000
Operating Temp.: -30~80°C
Outline Dim.: 192×122mm
Model: P0800WVF1MA00
Get A Quote
Size: 8" Electric Vehicle Charging Display
Resolution: 1024×600
Interface: LVDS
Brightness: 1500
Operating Temp.: -30~80°C
Outline Dim.: 192.8×116.9mm
Model: ET080WS01-Z1
Get A Quote
Size: 8" Electric Vehicle Charging Display
Resolution: 800×480
Interface: LVDS
Brightness: 1000
Operating Temp.: -30~80°C
Outline Dim.: 189×122mm
Model: TX20D200VM5BAA
Get A Quote
Size: 8" Electric Vehicle Charging Display
Resolution: 1280×720
Interface: LVDS
Brightness: 800
Operating Temp.: -30~85°C
Outline Dim.: 192.8×116.9mm
Model: AV080HDM-N19
Get A Quote
Size: 8" Electric Vehicle Charging Display
Resolution: 1280x768
Interface: LVDS
Brightness: 1200
Operating Temp.: -40~85°C
Outline Dim.: 189.5×119.4mm
Model: TX20D207VM0AAA
Get A Quote
Size: 8" Electric Vehicle Charging Display
Resolution: 1280×720
Interface: LVDS
Brightness: 1200
Operating Temp.: -30~85°C
Outline Dim.: 192.8×116.9mm
Model: A0800WXF1MB00
Get A Quote
Size: 8" Electric Vehicle Charging Display
Resolution: 1920×1200
Interface: LVDS
Brightness: 2000
Operating Temp.: -30~85°C
Outline Dim.: 179×119mm
Model: ET080WWV-R1
Get A Quote
Size: 9" Electric Vehicle Charging Display
Resolution: 1280×720
Interface: LVDS
Brightness: 850
Operating Temp.: -30~85°C
Outline Dim.: 225×145mm
Model: DD090IA-05A
Get A Quote
Size: 9" Electric Vehicle Charging Display
Resolution: 800×480
Interface: LVDS
Brightness: 1000
Operating Temp.: -40~85°C
Outline Dim.: 218×135mm
Model: TX23D203VM0BAA
Get A Quote
Size: 9" Electric Vehicle Charging Display
Resolution: 1280×720
Interface: LVDS
Brightness: 1100
Operating Temp.: -40~85°C
Outline Dim.: 211.5×128.08mm
Model: TM090JDKP01
Get A Quote
Size: 9" Electric Vehicle Charging Display
Resolution: 1024×600
Interface: LVDS
Brightness: 900
Operating Temp.: -30~80°C
Outline Dim.: 210×126mm
Model: ET090WS01-T
Get A Quote
Size: 10.1" Electric Vehicle Charging Display
Resolution: 1920×1200
Interface: LVDS
Brightness: 1400
Operating Temp.: -30~85°C
Outline Dim.: 236.96×163mm
Model: C101UAN01.0
Get A Quote
Size: 10.1" Electric Vehicle Charging Display
Resolution: 1920×1200
Interface: LVDS
Brightness: 900
Operating Temp.: -30~85°C
Outline Dim.: 278.94×155.25mm
Model: C101UAT03.0
Get A Quote
Size: 10.1" Electric Vehicle Charging Display
Resolution: 1280×800
Interface: LVDS
Brightness: 1000
Operating Temp.: -30~80°C
Outline Dim.: 229.8×149mm
Model: P1010WXF1MA01
Get A Quote
Size: 10.1" Electric Vehicle Charging Display
Resolution: 1280×800
Interface: LVDS
Brightness: 1000
Operating Temp.: -30~80°C
Outline Dim.: 229.8×149mm
Model: P1010WXF1MA01
Get A Quote
Size: 10.1" Electric Vehicle Charging Display
Resolution: 1280×720
Interface: LVDS
Brightness: 750
Operating Temp.: -30~85°C
Outline Dim.: 238.6×148mm
Model: DJ101IA-07A
Get A Quote
Size: 10.1" Electric Vehicle Charging Display
Resolution: 1280×800
Interface: LVDS
Brightness: 900
Operating Temp.: -30~80°C
Outline Dim.: 229.8×149mm
Model: TM101JDHG33-00
Get A Quote
Size: 10.1" Electric Vehicle Charging Display
Resolution: 1280×800
Interface: LVDS
Brightness: 1200
Operating Temp.: -30~80°C
Outline Dim.: 230.7×152.55mm
Model: G101ICE-LH2
Get A Quote
Size: 10.1" Electric Vehicle Charging Display
Resolution: 1920×1200
Interface: LVDS
Brightness: 800
Operating Temp.: -30~80°C
Outline Dim.: 232.1×153.2mm
Model: TX26D202VM0BAA
Get A Quote
Size: 10.1" Electric Vehicle Charging Display
Resolution: 1920×1080
Interface: LVDS
Brightness: 1100
Operating Temp.: -40~85°C
Outline Dim.: 237.69×142.7mm
Model: COG-VLSZT115-01
Get A Quote
Size: 10.1" Electric Vehicle Charging Display
Resolution: 800×1280
Interface: MIPI
Brightness: 750
Operating Temp.: -20~70°C
Outline Dim.: 166×249mm
Model: ET101WV30-TT
Get A Quote
Size: 10.1" Electric Vehicle Charging Display
Resolution: 1024×600
Interface: TTL
Brightness: 920
Operating Temp.: -20~70°C
Outline Dim.: 235×143mm
Model: P1010WSN1MA00
Get A Quote
Size: 10.1" Electric Vehicle Charging Display
Resolution: 1920×1080
Interface: LVDS
Brightness: 700
Operating Temp.: -30~85°C
Outline Dim.: 244.85×159.25mm
Model: AV101FHT-T10-28P0
Get A Quote
Size: 10.1" Electric Vehicle Charging Display
Resolution: 1540×720
Interface: LVDS
Brightness: 1450
Operating Temp.: -30~85°C
Outline Dim.: 290.8×147.93mm
Model: C101HAA01.0
Get A Quote
Size: 10.1" Electric Vehicle Charging Display
Resolution: 1920×1200
Interface: LVDS
Brightness: 1000
Operating Temp.: -20~70°C
Outline Dim.: 229.1×148.9mm
Model: ET101WU15-TT
Get A Quote
Size: 10.1" Electric Vehicle Charging Display
Resolution: 1024×600
Interface: TTL
Brightness: 700
Operating Temp.: -20~70°C
Outline Dim.: 252×150mm
Model: ET101WS06-TT
Get A Quote
Size: 10.1" Electric Vehicle Charging Display
Resolution: 1280×800
Interface: LVDS
Brightness: 1000
Operating Temp.: -20~70°C
Outline Dim.: 229.1×148.9mm
Model: ET101WX08-T
Get A Quote
Size: 10.1" Electric Vehicle Charging Display
Resolution: 1280×800
Interface: LVDS
Brightness: 1000
Operating Temp.: -30~80°C
Outline Dim.: 235.4×153.8mm
Model: NL12880BC16-02F
Get A Quote
Size: 10.1" Electric Vehicle Charging Display
Resolution: 1280×800
Interface: LVDS
Brightness: 1000
Operating Temp.: -20~70°C
Outline Dim.: 229.8×149mm
Model: TM101JDHG32-00
Get A Quote
Size: 10.1" Electric Vehicle Charging Display
Resolution: 1280×800
Interface: LVDS
Brightness: 1000
Operating Temp.: -20~70°C
Outline Dim.: 227.69×148.31mm
Model: G101EVN03.1
Get A Quote
Size: 10.1" Electric Vehicle Charging Display
Resolution: 1920×1200
Interface: eDP
Brightness: 1000
Operating Temp.: -20~70°C
Outline Dim.: 228.2×149mm
Model: GV101WUM-N40
Get A Quote
Size: 12.1" Electric Vehicle Charging Display
Resolution: 1280×800
Interface: LVDS
Brightness: 1100
Operating Temp.: -30~80°C
Outline Dim.: 277.7×180.6mm
Model: NL12880BC20-32F
Get A Quote
Size: 12.1" Electric Vehicle Charging Display
Resolution: 1280×800
Interface: LVDS
Brightness: 1100
Operating Temp.: -30~80°C
Outline Dim.: 277.7×180.6mm
Model: P1210WXF2MA01
Get A Quote
Size: 12.1" Electric Vehicle Charging Display
Resolution: 1280×800
Interface: LVDS
Brightness: 1500
Operating Temp.: -30~85°C
Outline Dim.: 281.78×183.17mm
Model: P1210WXF2MA00
Get A Quote
Size: 12.1" Electric Vehicle Charging Display
Resolution: 1280×800
Interface: LVDS
Brightness: 1000
Operating Temp.: -30~80°C
Outline Dim.: 278×184mm
Model: G121ICE-LH1
Get A Quote
Size: 12.1" Electric Vehicle Charging Display
Resolution: 1024×768
Interface: LVDS
Brightness: 1000
Operating Temp.: -30~75°C
Outline Dim.: 260.5×204mm
Model: G121XCE-LM1
Get A Quote
Size: 12.1" Electric Vehicle Charging Display
Resolution: 1280×800
Interface: LVDS
Brightness: 750
Operating Temp.: -20~70°C
Outline Dim.: 293×198mm
Model: ET121WX02-TT
Get A Quote
Size: 12.1" Electric Vehicle Charging Display
Resolution: 1024×768
Interface: LVDS
Brightness: 1300
Operating Temp.: -30~80°C
Outline Dim.: 260.5×203mm
Model: P1210XGF1MA00
Get A Quote
Size: 12.1" Electric Vehicle Charging Display
Resolution: 1024×768
Interface: LVDS
Brightness: 1000
Operating Temp.: -40~80°C
Outline Dim.: 260.5×203mm
Model: TX31D207VM0BAA
Get A Quote
Size: 12.1" Electric Vehicle Charging Display
Resolution: 1024×768
Interface: LVDS
Brightness: 900
Operating Temp.: -30~70°C
Outline Dim.: 260.5×203mm
Model: COM121H9M21SSS
Get A Quote
Size: 12.1" Electric Vehicle Charging Display
Resolution: 800×600
Interface: LVDS
Brightness: 1500
Operating Temp.: -30~85°C
Outline Dim.: 261.65×203mm
Model: G121STN02.1
Get A Quote
Size: 12.1" Electric Vehicle Charging Display
Resolution: 800×600
Interface: LVDS
Brightness: 1500
Operating Temp.: -30~70°C
Outline Dim.: 276x209mm
Model: LQ121S1LG86
Get A Quote
Size: 12.1" Electric Vehicle Charging Display
Resolution: 1280×800
Interface: LVDS
Brightness: 1000
Operating Temp.: -30~85°C
Outline Dim.: 278×184mm
Model: G121EAN01.2
Get A Quote
Size: 13.3" Electric Vehicle Charging Display
Resolution: 1920×1080
Interface: eDP
Brightness: 1000
Operating Temp.: -20~70°C
Outline Dim.: 308×183.45mm
Model: ET133FH03-TT
Get A Quote
Size: 13.3" Electric Vehicle Charging Display
Resolution: 1920×1080
Interface: LVDS
Brightness: 1000
Operating Temp.: -20~70°C
Outline Dim.: 308×186mm
Model: P1330FHF1MA00
Get A Quote
Size: 14" Electric Vehicle Charging Display
Resolution: 1920×1080
Interface: LVDS
Brightness: 800
Operating Temp.: -20~70°C
Outline Dim.: 315.31×184.49mm
Model: P1400FHF1MA00
Get A Quote
Size: 15" Electric Vehicle Charging Display
Resolution: 1024×768
Interface: LVDS
Brightness: 800
Operating Temp.: -20~75°C
Outline Dim.: 326.5×253.5mm
Model: G150XAN02.1
Get A Quote
Size: 15" Electric Vehicle Charging Display
Resolution: 1600×1200
Interface: LVDS
Brightness: 1000
Operating Temp.: -30~70°C
Outline Dim.: 318.7×242.5mm
Model: TM150XDHG01
Get A Quote
Size: 15" Electric Vehicle Charging Display
Resolution: 1920×720
Interface: LVDS
Brightness: 1200
Operating Temp.: -40~85°C
Outline Dim.: 374.5×154.5mm
Model: TX38D203VM0BAA
Get A Quote
Size: 15" Electric Vehicle Charging Display
Resolution: 1024×768
Interface: LVDS
Brightness: 1700
Operating Temp.: -20~70°C
Outline Dim.: 326.5×253.5mm
Model: P1500XGF3MA00
Get A Quote
Size: 15" Electric Vehicle Charging Display
Resolution: 1024×768
Interface: LVDS
Brightness: 1500
Operating Temp.: -30~80°C
Outline Dim.: 326.5×253.5mm
Model: DV150X0M-N17
Get A Quote
Size: 15" Electric Vehicle Charging Display
Resolution: 1024×768
Interface: LVDS
Brightness: 1800
Operating Temp.: -30~70°C
Outline Dim.: 326.5×253.5mm
Model: G150XTN06.A
Get A Quote
Size: 15" Electric Vehicle Charging Display
Resolution: 1024×768
Interface: LVDS
Brightness: 1800
Operating Temp.: -30~70°C
Outline Dim.: 326.5×253.5mm
Model: G150XJE-LM1
Get A Quote
Size: 15.6" Electric Vehicle Charging Display
Resolution: 1920×1080
Interface: LVDS
Brightness: 1000
Operating Temp.: -30~85°C
Outline Dim.: 363.8×215.9mm
Model: G156HAN04.0
Get A Quote
Size: 15.6" Electric Vehicle Charging Display
Resolution: 1366×768
Interface: LVDS
Brightness: 1250
Operating Temp.: -30~80°C
Outline Dim.: 363.8×215.9mm
Model: NL13676BC25-07F
Get A Quote
Size: 15.6" Electric Vehicle Charging Display
Resolution: 1920×1080
Interface: LVDS
Brightness: 1000
Operating Temp.: -30~80°C
Outline Dim.: 363.8×215.9mm
Model: P1560FHF2MA00
Get A Quote
Size: 15.6" Electric Vehicle Charging Display
Resolution: 1920×1080
Interface: LVDS
Brightness: 1200
Operating Temp.: -30~80°C
Outline Dim.: 363.8×215.9mm
Model: G156HCE-LH1
Get A Quote
Size: 15.6" Electric Vehicle Charging Display
Resolution: 1920×1080
Interface: LVDS
Brightness: 1000
Operating Temp.: -20~70°C
Outline Dim.: 360×212.3mm
Model: ET156FH06-T
Get A Quote
Size: 15.6" Electric Vehicle Charging Display
Resolution: 1920×1080
Interface: LVDS
Brightness: 1500
Operating Temp.: -30~85°C
Outline Dim.: 367.86×219.51mm
Model: TX40D202VM0BAA
Get A Quote
Size: 15.6" Electric Vehicle Charging Display
Resolution: 1920×1080
Interface: LVDS
Brightness: 1500
Operating Temp.: -30~70°C
Outline Dim.: 363.8×215.9mm
Model: G156HAN04.1
Get A Quote
Size: 15.6" Electric Vehicle Charging Display
Resolution: 1920×1080
Interface: LVDS
Brightness: 850
Operating Temp.: -30~85°C
Outline Dim.: 363.7×215.7mm
Model: HSD156JUW2-A12
Get A Quote
Size: 15.6" Electric Vehicle Charging Display
Resolution: 1920×1080
Interface: eDP
Brightness: 1500
Operating Temp.: -30~85°C
Outline Dim.: 363.8×215.9mm
Model: NL192108BC18-06F
Get A Quote
Size: 15.6" Electric Vehicle Charging Display
Resolution: 1920×1080
Interface: LVDS
Brightness: 1500
Operating Temp.: -20~80°C
Outline Dim.: 353.36×208.09mm
Model: ET156FH01-RT
Get A Quote
Size: 18.5" Electric Vehicle Charging Display
Resolution: 1920×1080
Interface: eDP
Brightness: 1800
Operating Temp.: -30~70°C
Outline Dim.: 429.3×253.06mm
Model: G185HAN01.4
Get A Quote
Size: 18.5" Electric Vehicle Charging Display
Resolution: 3840×2160
Interface: eDP
Brightness: 1400
Operating Temp.: -20~70°C
Outline Dim.: 430.96×252.04mm
Model: P1850UHF1MA00
Get A Quote
Size: 18.5" Electric Vehicle Charging Display
Resolution: 1920×1080
Interface: LVDS
Brightness: 1000
Operating Temp.: -30~80°C
Outline Dim.: 430.4×254.6mm
Model: ET185FH21-K
Get A Quote
Size: 18.5" Electric Vehicle Charging Display
Resolution: 1920×1080
Interface: LVDS
Brightness: 2000
Operating Temp.: -20~70°C
Outline Dim.: 430×254mm
Model: ET185FH01-T
Get A Quote
Get in Touch:

Design ingenuity. Manufacturing agility and scale. Supply chain innovation.
No matter how complex or demanding the project, we're helping today's technology innovators solve it.
Get started with a trusted partner...
Name*
Job title
Companu name
Email*
Phone
Message
Electric Vehicle Charging Display

Electric Vehicle Charging Display

Why Electric Vehicle Charging Displays Matter
The display is the primary Human Machine Interface (HMI) of every charging station. It directly impacts user experience, charging efficiency, payment interaction, brand perception, and operational reliability.

Modern EV charging displays must provide:
Clear visibility under direct sunlight
Responsive touch interaction
Reliable operation in extreme temperatures
Long service life for 24/7 operation
Vandal-resistant construction
Smart connectivity integration
Easy maintenance and remote management

Eurotech develops EV charging displays specifically engineered to meet these challenges.

Poor Sunlight Visibility
-Standard commercial displays become difficult to read in direct sunlight, reducing user experience and operational efficiency.

Eurotech Solution
1000~2500 nits ultra-high brightness
Sunlight-readable LCD technology
Optical bonding enhancement
Anti-glare surface treatment
Harsh Outdoor Environments

Charging stations operate continuously in rain, snow, dust, humidity, and intense UV exposure.
Eurotech Solution
Industrial-grade TFT LCD modules
UV-resistant cover glass
Wide temperature operation
IP-rated front surface design
Weather-resistant materials
Frequent Touchscreen Failures

Public charging stations require highly durable touch interfaces capable of withstanding millions of interactions.
Eurotech Solution
Industrial PCAP touch technology
Glove operation support
Water-resistant touch algorithms
Chemically strengthened cover glass
IK-rated impact resistance
System Integration Complexity

Many charging equipment manufacturers struggle with integrating displays, touchscreens, controllers, and communication systems.
Eurotech Solution
Complete one-stop integration services:
TFT LCD Display
Touch Screen
Cover Glass
Optical Bonding
Embedded Mainboard
Android/Linux Platform
Custom Firmware Development

Key Features of Eurotech Electric Vehicle Charging Displays
Ultra High Brightness Display
Designed for outdoor charging stations exposed to direct sunlight.
Benefits
1000~2500 nits brightness
Excellent outdoor readability
Improved user interaction
Reduced operational errors

Projected Capacitive Touch Technology
High-performance multi-touch operation for modern charging interfaces.
Benefits
Fast response
Multi-touch capability
Glove touch support
Wet finger operation
Long service life

Optical Bonding Technology
Eliminates air gaps between LCD and cover glass.

Benefits
Improved contrast
Reduced reflection
Enhanced durability
Better sunlight readability

Wide Temperature Reliability
Built for demanding outdoor charging environments.
Performance Range
Operating Temperature: -30°C to +85°C
Storage Temperature: -40°C to +90°C

Rugged Cover Glass Design
Engineered for public infrastructure deployment.

Optional Features

Anti-Glare (AG)
Anti-Reflection (AR)
Anti-Fingerprint (AF)
IK08 / IK10 Protection
Custom Silk Printing

Electric Vehicle Charging Display Applications

DC Fast Charging Stations
High-power public charging systems require large, sunlight-readable displays for charging information, payment processing, and user interaction.
Recommended Features
15.6" to 32"
High brightness
PCAP touch
Optical bonding
AC Charging Stations

Commercial and residential charging equipment benefits from compact, energy-efficient display solutions.
Recommended Features
4.3" to 15.6"
Touch integration
Cost-effective design
Fleet Charging Infrastructure

Fleet operators require reliable monitoring and management interfaces.
Recommended Features
Industrial-grade reliability
Network connectivity
Remote diagnostics
Smart Parking & Charging Systems

Integrated parking and charging solutions demand intuitive user interfaces and real-time information displays.
Recommended Features
Interactive touchscreens
Advertising capability
Cloud connectivity
Renewable Energy Charging Networks

Solar-powered and battery-integrated charging stations require advanced visualization interfaces.
Recommended Features
Energy monitoring display
Smart grid communication
Dynamic data visualization
Custom Touchscreen & Cover Glass Development

Eurotech provides complete touchscreen and cover lens engineering services.
Custom Capabilities

Cover Glass Design
Thickness customization
Shape customization
CNC machining
Logo printing
Decorative borders
Surface Treatments
AG coating
AR coating
AF coating
Durability Enhancement
Chemically strengthened glass
IK-rated protection
Outdoor weather resistance

Embedded Mainboard & HMI Integration
Unlike traditional display suppliers, Eurotech offers complete HMI hardware solutions.
Mainboard Development Services
Operating Platforms
Android
Linux
RTOS
Communication Interfaces
CAN Bus
RS232
RS485
USB
Ethernet
WiFi
Bluetooth
Optional Integration
RFID Authentication
NFC Reader
QR Payment
Camera Module
Audio System
Cloud Connectivity

This significantly reduces development time for charging equipment manufacturers.
Manufacturing Capabilities
Eurotech provides full lifecycle support from concept development to mass production.
Engineering Services
Product Definition
Mechanical Design
Electrical Design
Touch Integration
Firmware Development
Reliability Validation
Production Services
TFT LCD Integration
Optical Bonding
Touchscreen Assembly
SMT Assembly
Functional Testing
Burn-in Testing
Mass Production
Quality Assurance
ISO Manufacturing Process
100% Functional Testing
Reliability Verification
Environmental Testing
Long-Term Supply Support
Customer Success Case
Outdoor DC Fast Charging Network Project
Customer Challenge

A European EV charging equipment manufacturer required a display solution capable of operating reliably under intense sunlight, rain exposure, and heavy public usage.
Eurotech Solution
21.5-inch high-brightness LCD
2000 nits brightness
PCAP touchscreen
Optical bonding
IK10 cover glass
Custom Android mainboard
Results
Improved outdoor visibility by over 300%
Reduced service requests
Faster deployment cycle
Enhanced user experience

Why Choose Eurotech for Electric Vehicle Charging Displays
Complete Display + Touch + Mainboard Integration

Eurotech supplier for the entire HMI solution.
Deep Industrial Display Expertise
Years of experience serving industrial, transportation, energy, and smart infrastructure markets.
High Customization Capability
Tailored solutions based on customer requirements.
Faster Time-to-Market
Integrated engineering and manufacturing resources reduce project development cycles.
Long-Term Supply Commitment
Stable product lifecycle management for infrastructure projects.
Global Project Experience
Supporting charging equipment manufacturers worldwide.


Get in touch Contact Us
Eurotech is a worldwide leading display technology company focused on advanced innovative visual technology systems in high-growth markets, with deep understanding of the needs of the modern technology world..
Follow Us:

Links

Contact us

Tel:(852) 6942 7360
Tel:(86) 755 8395 2292
E-mail:lcdsource@eurotech-lcd.com
E-mail:info@eurotech-ic.com
ShenZhen office:Building A, Jinfeng Zhihui Valley, No. 45, Yonghe Road, Bao'an District,Shenzhen
HK office:Unit 1003-1004,10/F, Block4, Nam Fung Industrial City, 18 Tin Hau Road,Tuen Mun, HONGKONG
For Blog Updates

Subscribe to get the latest relevant information.Fill in your info.
© Eurotech All Rights Reserved
